H418 Light Type Champion Snatch Block with Hook

banner
Product Details

H418 Light Type Champion Snatch Block with Hook


Product Features:

• Forged alloy heat treated hook.

• Forged steel swivel tees and yokes .

• Hook from H418 and shackle assemblies from H419 on 4-1/2” through 14” sizes can be interchanged.

• Can be furnished with bronze bushings or roller bearings.

• Opening feature permits insertion of rope while block is suspended from gin-pole.

• 3” thru 18” 418 blocks have exclusive bolt-retaining spring to assure no lost bolts.

• Pressure lube fittings.

• 3” - 10” feature dual rated Wireline sheaves.

• Fatigue rated.

• Ultimate Load is 4 times the Working Load Limit.


1





Part No.



Size

S.W.L

Dia. of Rope

N.W.

(inch)

(ton)

(inch)

(kgs)

H4183000

3

2

3/8

2.3

H4184102

4 1/2

4

1/2

5.74

H4186000

6

8

3/4

11.5

H4188000

8

8

3/4

15.75

H418T100

10

8

3/4

21.9

H418T120

12

8

3/4

30

H418T140

14

8

3/4

36

H418T160

16

15

7/8

99

H418T180

18

15

1

112.5
