YC Standard Beam Clamp
Features:
Beam clamp model YC
Working Load Limited (WLL): 1-10T
Flexible application based on wide adjustment range.
The spindle can be secured against loosening.
Option, small dimensions for applications at beams with low base height.
Overload is prohibited.
Model | WLL | Jaw Opening | Weight |
(TON) | (MM) | (KG) | |
YC1 | 1 | 75-220 | 3.8 |
YC2 | 2 | 75-220 | 4.6 |
YC3 | 3 | 80-320 | 9 |
YC5 | 5 | 80-320 | 11 |
YC10 | 10 | 90-320 | 16 |
